Inovance CS200 User Manual

Chapter 5 Function Code Table
- 84 -
5.3 Parameters of Level-III Menu (Group F)
Level-III menu includes the parameters for adjusting output performance of the AC drive and factory parameters.
The parameters in level-III menu rarely need be modied.
To enter the level-III menu, input the password set in FF0.00 correctly.
Function
Code
Parameter Name Description Setting Range Default
Group F0: Motor Parameters
F0.00
Stator resistance
(asynchronous
motor)
These ve parameters are asynchronous motor
parameters. They are unavailable on the motor
nameplate and are obtained through motor auto-tuning.
You can obtain F0.00 to F0.02 through the motor auto-
tuning 1 and obtain all these ve parameters through
the motor auto-tuning 3. Besides these ve parameters,
you can obtain the encoder phase sequence and
current loop PI parameters through the motor auto-
tuning 2.
When the rated motor power (A0.01) is modied, the
AC drive modies the value of these ve parameters
automatically to the parameter value for standard Y
series motor.
(≤ 55 kW): 0.001
to 65.535 Ω
(> 55 kW): 0.0001
to 6.5535 Ω
Motor
dependent
F0.01
Rotor resistance
(asynchronous
motor)
(≤ 55 kW)
0.001 to 65.535 Ω
(> 55 kW)
0.0001 to 6.5535
Ω
Motor
dependent
F0.02
Leakage inductive
reactance
(asynchronous
motor)
(≤ 55 kW): 0.01 to
655.35 mH
(> 55 kW): 0.001
to 65.535 mH
Motor
dependent
F0.03
Mutual inductive
reactance
(asynchronous
motor)
(≤ 55 kW): 0.1 to
6553.5 mH
(> 55 kW): 0.01 to
655.35 mH
Motor
dependent
F0.04
No-load current
(asynchronous
motor)
(≤ 55 kW): 0.01 to
A0.03
(> 55 kW): 0.1 to
A0.03
Motor
dependent
