Chapter 3 Mechanical and Electrical Installation
- 25 -
Figure 3-5 Embedded mounting of the CS200 (plastic housing)
Install the AC drive from the
front of the control cabinet
Back panel of the
control cabinet
3. Surface mounting of the CS200 (sheet metal housing)
Figure 3-6 Surface mounting of the CS200 (sheet metal housing)
Install the AC drive from the
front of the control cabinet.
Fix four screws.
Back panel of
control cabinet
