Chapter 5 Function Code Table
- 64 -
Function
Code
Parameter Name Function Description Setting Range Default
b6.03
Brake release current
in the upward direction
It is used to set the percentage of the AC drive
output current to the rated motor current (A0.03).
When the percentage of the AC drive output current
to the rated motor current reaches this value, the
brake release command is output immediately
(output function 1 enabled).
For details, see the description of section 4.10.
0.0% to
150.0%
30.0%
b6.04 Brake release time in
the upward direction
It is used to set the time it takes the mechanical
brake from starting to release to releasing
completely. Within the time, the AC drive keeps the
brake release frequency output. For details, see the
description of section 4.10.
0.00s to 5.00s 0.20s
b6.05 Brake apply frequency
in the upward direction
When the output frequency during deceleration
(after the RUN command is cancelled) falls below
this value, the brake apply command is immediately
output (output function 1 disabled).
For details, see the description of section 4.10.
Min. frequency
(b1.03) to
20.00 Hz
2.00 Hz
b6.06 Brake apply time in
the upward direction
It is used to set the time it takes the mechanical
brake from starting to apply to applying completely.
Within the time, the AC drive keeps the brake apply
frequency output. For details, see the description of
section 4.10.
0.00s to 5.00s 0.20s
