Inovance CS500 User Manual

Function
Code
Parameter Name Setting Range Min. Unit Default Property
2: Switchover between X and Y
3: Switchover between X and "X and
Y superposition"
4: Switchover between Y and "X and
Y superposition"
F0-08
Preset frequency
0.00 Hz to maximum frequency (valid
when frequency source is digital
setting)
0.01 Hz 50.00 Hz ƿ
F0-10
Maximum frequency 50.00–150.00 Hz
0.01 Hz 50.00 Hz ƾ
F0-11
Source of output
frequency upper limit
0: Set by F0-12
1: AI1
2: AI2
3: AI3
5: Via communication
Other: Reserved
1 0 ƾ
F0-12
Output frequency
upper limit
"Lower limit of output frequency"
(F0-14) to "Maximum frequency"
(F0-10)
0.01 Hz 50.00 Hz ƿ
F0-13
Upper limit offset
0.00 Hz to maximum frequency
(F0-10)
0.01 Hz 0.00 Hz ƿ
F0-14
Output frequency
lower limit
0.00 Hz to "Output frequency upper
limit" (F0-12)
0.01 Hz 0.00 Hz ƿ
F0-15
Carrier frequency 0.5–16.0 kHz
0.1 kHz
Model
dependent
ƿ
F0-16
Carrier frequency
adjustment selection
0: Fixed PWM, temperature-based
carrier frequency adjustment invalid
1: Random PWM,
temperature-based carrier frequency
adjustment invalid
2: Fixed PWM, temperature-based
carrier frequency adjustment valid
3: Random PWM,
temperature-based carrier frequency
adjustment valid
1 2 ƿ
Group F1: Motor parameters
F1-00 Motor type selection
0: Common asynchronous motor
1: Variable frequency asynchronous
motor
1 0 ƾ
F1-01
Rated motor power 0.4–1000.0 kW
0.1 kW
Model
dependent
ƾ
F1-02
Rated motor voltage 0–800 V
1 V 380 V ƾ
F1-03
Rated motor current 0.00–655.35 A
0.01 A (

55 kW);
0.1 A (>
55 kW)
Model
dependent
ƾ
F1-04
Rated motor
frequency
0.00 Hz to maximum frequency
0.01 Hz 50.00 Hz ƾ
F1-05
Rated motor
rotational peed
0–3000 RPM
1 RPM 1460 RPM ƾ
F1-06
Stator phase
resistance
ƿ
F1-07 Rotor phase
0.001–65.535  (AC drive power 
55 kW)
0.0001–6.5535  (AC drive power >
0.001  (
55 kW);
0.0001
(> 55
Model
dependent
ƿ
efesotomas
y
on.com
