Inovance CS500 User Manual

Function
Code
Parameter Name Setting Range Min. Unit Default Property
resistance of
asynchronous motor
55 kW)
0.001–65.535  (AC drive power 
55 kW)
0.0001–6.5535  (AC drive power >
55 kW)
kW)
F1-08
Leakage inductance
of asynchronous
motor
0.1–6553.5 mH (AC drive power  55
kW)
0.01–655.35 mH (AC drive power >
55 kW)
0.01 mH
( 55 kW);
0.001 mH
(> 55 kW)
Model
dependent
ƿ
F1-09
Mutual inductance of
asynchronous motor
0.1–6553.5 mH (AC drive power  55
kW)
0.01–655.35 mH (AC drive power >
55 kW)
0.1 mH (
55 kW);
0.01mH (>
55 kW)
Model
dependent
ƿ
F1-10
No-load excitation
current of
asynchronous motor
0.01–650.00 A (AC drive power  55
kW)
0.1–650.00 A (AC drive power > 55
kW)
0.01 A (
55 kW);
0.1 A (>
55 kW)
Model
dependent
ƿ
F1-11
Motor auto-tuning
mode
0: No auto-tuning
1: Static auto-tuning (certain motor
parameters obtained)
2: Complete auto-tuning (complete
motor parameters obtained)
3: Static auto-tuning (complete motor
parameters obtained)
1 0
ƾ
Group F2: Vector control parameters
F2-00
F2-00 Speed loop proportional gain 1
1 60 ƿ
F2-01
F2-01 Speed loop integral time 1
0.01s 0.50s ƿ
F2-02
F2-02 Switchover frequency 1
0.01 Hz 5.00H z ƿ
F2-03
F2-03 Speed loop proportional gain 2
1 20 ƿ
F2-04
F2-04 Speed loop integral time 2
0.01s 1.00s ƿ
F2-05
F2-05 Switchover frequency 2
0.01 Hz 10.00 Hz ƿ
F2-06
Vector control slip
compensation
coefficient
50%–200%
1% 100% ƿ
F2-07
Filter time constant
of speed loop
0.000–0.100s
0.001s 0.000s ƿ
F2-08
Torque control
0: Invalid
1: Valid
1 0 ƿ
F2-09
Torque upper limit
source
0: F2-10
1: AI1
2: AI2
3: AI3
5: Via communication
1 0 ƿ
F2-10
Torque upper limit 0.0%–200.0%
0.1% 150.0% ƿ
F2-11
PPR of the encoder 0–65535
1 1024 ƾ
F2-12
A
B phase sequence
of incremental
encoder
0: Phase sequence not reversed
1: Phase sequence reversed
1 0 ƾ
Group F3: V/F control parameters
F3-00 V/F curve setting 0: Linear V/F curve 1 0 ƾ
