Option Selection
‑105‑
Name
Option Model
Applicable AC Drive
Model
Function
Cable
External LED
operating panel
MDKE‑10
Applicable to all
models
Connected to the external LED operating
panel through the RJ45
External LCD
operating panel
SOP‑20‑880
Applicable to all
models
External LCD operating panel, which can
be used for parameter copy and download
SOP‑20‑880
mounting base
CP600‑BASE1
Applicable to all
models
The SOP‑20‑880 can be installed to the
cabinet door by using the mounting base.
MDKE‑10
mounting base
MD580‑AZJ1
Applicable to all
models
The MDKE‑10 can be installed to the
cabinet door by using the mounting base.
Extension cable MDCAB
Applicable to all
models
The standard 8‑conductor cable can
connect to the LED and LCD operating
panel.
Main circuit cable
Lugs manufactured by Suzhou Yuanli are
recommended. For details of recommended
lugs, see "
3.3.2 Cable Selection
"
on page 58
.
It is recommended that the input and
output main circuit cables use
symmetrical shielded cables. Compared
with four‑conductor cables, symmetrical
shielded cables can reduce
electromagnetic radiation in the whole
transmission system. It is recommended
that power cables use symmetrical
shielded cables.
Control circuit
cable
All control circuit cables must be shielded cables. Use a separate shielded cable for each
type of analog signal. It is recommended that digital signal cables use shielded twisted
pair (STP) cables.
