Inovance MD580 Series User Manual

Option Selection
‑171‑
4.5 Extension Card
4.5.1 List of Expansion Cards
The MD580 series AC drive supports multiple expansion cards to communicate with
field buses. It also supports multiple encoder types for programming and secondary
development. For detailed functions and configurations of the expansion card, see
related user guide.
Table 4–43 List of expansion cards
Name
Model Function Remarks
CANopen bus
adapter card
MD580–SI‑
CAN1
CANopen communication
adapter card
Applicable to all
models
Modbus RTU bus
adapter card
MD580–SI‑
RS1
PROFIBUS DP communication
adapter card
Applicable to all
models
PROFIBUS DP bus
adapter card
MD580–SI‑
DP1
PROFIBUS DP communication
card
Applicable to all
models
PROFINET IO
industrial Ethernet
card
MD580–SI‑
PN1
PROFINET IO communication
adapter card
Applicable to all
models
Modbus TCP
industrial Ethernet
card
MD580–SI‑
EM1
Modbus TCP communication
adapter card
Applicable to all
models
Resolver interface
card
MD38PG4
Applicable to the resolver;
excitation frequency: 10 kHz;
DB9 interface
To meet the MD38PG4
requirements, the excitation
input DC resistance of the
resolver must be greater than 17
Ω. Failure to comply may result
in MD38PG4 exceptions. Select a
resolver with a maximum of four
pole pairs. Otherwise, MD38PG4
will be overloaded.
Applicable to all
models
