2 System Commissioning
2
The following gure shows the setting of increasing the called oor to 5.
Figure 2-2 Setting the called oor
PRG
SET
UP
SET
PRG
Default
(Current floor
)
Function menu mode
Function menu edit mode
...
FA
Fb
FC
F0
F1
F2
F3
UP
...
Menu Description
The function menus displayed on the keypad are described as follows:
1. F-0: display of oor and running direction
The F0 menu is displayed on the keypad by default upon power-on. The rst LED indicates the run-
ning direction, while the last two LEDs indicate the current oor number of the elevator.
When the elevator stops, the rst LED has no display. When the elevator runs, the rst LED blinks to
indicate the running direction.
When a system fault occurs, the 7-segment LEDs automatically display the fault code and blink. If the
fault is reset automatically, the F0 menu is displayed.
Running
direction
Current floor
Stop state: no display
RUN state: running direction in blinking
Fault state: fault code in blinking
