INSTEON Hub: Developer’s Guide
Page 14 © 2013 INSTEON
0x56 ALL-Link Cleanup Failure
Report
31
R: 0x02 0x56 <0x01>
<ALL-Link Group>
<ID high byte> <ID middle byte> <ID low byte>
0x57
ALL-Link Record Response
39
R: 0x02 0x57
<ALL-Link Record Flags>
<ALL-Link Group>
<ID high byte> <ID middle byte> <ID low byte>
<Link Data 1> <Link Data 2> <Link Data 3>
0x58 ALL-Link Cleanup Status
Report
32
R: 0x02 0x58 <0x06>
ALL-Link Cleanup sequence completed
R: 0x02 0x58 <0x15>
ALL-Link Cleanup sequence aborted due to INSTEON traffic
0x59
Database Record Found
32
R: 0x02 0x59 <Database Address high byte>
<Database Address low byte (low nibble should be 0xF | 0x8)>
<ALL-Link Record Flags>
<ALL-Link Group>
<ID high byte> <ID middle byte> <ID low byte>
<Link Data 1> <Link Data 2> <Link Data 3>
Commands Sent from the Host to an IM
0x60
Get IM Info
48
S: 0x02 0x60
R: 0x02 0x60
<ID high byte> <ID middle byte> <ID low byte>
<Device Category> <Device Subcategory> <Firmware Revision>
<0x06>
0x61
Send ALL-Link Command
29
S: 0x02 0x61
<ALL-Link Group>
<ALL-Link Command>
<0xFF | 0x00>
R: 0x02 0x61
<ALL-Link Group>
<ALL-Link Command>
<0xFF | 0x00>
<0x06>
0x62 Send INSTEON Standard or
Extended Message
19
S: 0x02 0x62
<INSTEON Standard message (6 bytes, excludes From Address) |
INSTEON Extended message (20 bytes, excludes From Address)>
R: 0x02 0x62
<INSTEON Standard message (6 bytes, excludes From Address) |
INSTEON Extended message (20 bytes, excludes From Address)>
<0x06>
0x63
Send X10
27
S: 0x02 0x63
<Raw X10> <X10 Flag>
R: 0x02 0x63
<Raw X10> <X10 Flag>
<0x06>
0x64
Start ALL-Linking
33
S: 0x02 0x64
<0x00 (IM is Responder) | 0x01 (IM is Controller) |
0x03 (IM is either) | 0xFF (Link Deleted)
bit2 set = use Set Database Link Data for next Link>
<ALL-Link Group>
R: 0x02 0x64
<0x00 (IM is Responder) | 0x01 (IM is Controller) |
0x03 (IM is either) | 0xFF (Link Deleted)>
<ALL-Link Group>
<0x06>
0x65
Cancel ALL-Linking
34
S: 0x02 0x65
R: 0x02 0x65
<0x06>
0x66
Set Host Device Category
49
S: 0x02 0x66
<Device Category> <Device Subcategory> <0x00 | Firmware Revision>

INSTEON Hub Specifications

General

Product Name	INSTEON Hub
Model Number	2245-222
Connectivity	Ethernet
Communication Protocol	INSTEON
Operating Temperature	0°C to 40°C (32°F to 104°F)
Operating Humidity	85% non-condensing
