13
Front & Rear Panels—Continued
E FRONT L/R, CENTER, SURR/ZONE 4 L/R,
SURR BACK/ZONE 3 L/R, FRONT HIGH L/R,
and FRONT WIDE/ZONE 2 L/R
These terminal posts are for connecting the front
L/R, center, surround/zone 4 L/R, surround
back/zone 3 L/R, front high L/R, and
front wide/zone 2 L/R speakers.
The FRONT L/R and SURR BACK/ZONE 3 L/R
terminal posts can be used with front speakers and
surround back speakers respectively, or used to bi-
amp or bridge the front speakers. See “Bi-amping
the Front Speakers” on page 21 and “Bridging the
Front Speakers” on page 22.
The FRONT WIDE/ZONE 2 L/R terminals can be
used with front wide speakers or zone 2 speakers
respectively, or used to connect the passive sub-
woofers.
See “Connecting Zone 2” on page 137.
The SURR BACK/ZONE 3 L/R terminals can be
used with surround back speakers respectively, or
used to connect the speakers in Zone 3.
See “Connecting Zone 3” on page 139.
The SURR/ZONE 4 L/R terminals can be used with
surround speakers respectively, or used to connect
the speakers in Zone 4.
See “Connecting Zone 4” on page 140.
F SIRIUS antenna
(North American models)
This jack is for connecting a SIRIUS Satellite Radio
antenna, sold separately (see the separate SIRIUS
instructions).
See pages 18 to 44 for connection information.
To Next Page
