Integra DTR-70.1 User Manual

59
First Time Setup—Continued
Using Audyssey MultEQ
®
XT
Enter
qwer
On/Standby
Speaker setup
microphone
Notes:
• If any of your speakers is 4 ohms, change
“Speaker Impedance” setting before running
Audyssey MultEQ XT Room Correction and
Speaker Setup (see page 54).
• If the AV receiver is muted, it will be unmuted
automatically when Audyssey MultEQ XT
Room Correction and Speaker Setup starts.
• Room correction and speaker setup cannot be
performed while a pair of headphones is
connected.
• It takes about 30 minutes to complete the room
correction and speaker setup for eight positions.
Total measurement time varies depending on the
number of speakers.
• Do not disconnect the speaker setup microphone
during the room correction and speaker setup,
unless you want to cancel the setup.
• Do not connect or disconnect any speakers during
the room correction and speaker setup.
1
Turn on the AV receiver and the
connected TV.
On the TV, select the input to which the
AV receiver is connected.
2
Set the speaker setup micro-
phone at the Main Listening Posi-
tion a (page 58), and connect it
to the Setup Mic jack.
The speaker setting menu appears.
If you change these settings, refer to
step 5 on “Speaker Settings” (page 54)
or step 4 on “Setting the Powered
Zone 2/3/4” (page 141).
3
When you’ve finished, press the
[Enter] button.
Notes:
• Before starting Audyssey MultEQ
XT Room Correction and Speaker
Setup, arrange the room and connect
the speakers as you would for
enjoying movies. Changes to the
room after auto setup requires you
run the auto setup again, as room EQ
characteristics may have changed.
• When starting the room correction
and speaker setup, do not stand
between the speakers and
microphone, and avoid obstacles
blocking the path between speakers
and microphone. This will produce
inaccurate results.
• Position the microphone at ear height
of a seated listener with the
microphone tip pointed directly at
the ceiling using a tripod. Do not
hold the microphone in your hand
during measurements as this will
produce inacurate results.
MultEQ XT: Auto Setup
Speakers Type(Front)
Passive Subwoofer
Powered Zone2
Powered Zone3
Powered Zone4
Normal
Not Use
Not Act
Not Act
Not Act
MultEQ XT: Auto Setup
Please place setup microphone at
center of listening area at
ear height.
Next
