Embedded Intel® Atom Processor D2700 with Intel® NM10 Express Chipset
14
2 Intel
®
Embedded Board D2700
Overview
2.1 Overview
2.1.1 Feature Summary
Table 1 summarizes the features of Intel
®
Embedded Board D2700.
Table 1. Feature Summary
Form Factor of
D2700 Embedded
Board
Mini-ITX (6.7 inches by 6.7 inches [170 millimeters by 170 millimeters])
compatible with microATX
Passively-cooled, soldered-down Dual-Core Intel
®
D2700 with
integrated graphics and integrated memory controller
Two 204-pin DDR3 SDRAM Small Outline Dual Inline Memory Module
(SO-DIMM) sockets
Support for DDR3 1066 MHz, DDR3 1333 MHz, and DDR3 1600 MHz
SO-DIMMs
Note: DDR3 1333 MHz and DDR3 1600 MHz memory will run at 1066 MHz
Support for up to 4 GB of system memory on a single SO-DIMM (or two 2 GB
SO-DIMMs)
Intel
®
NM10 Express Chipset
Multi-streaming 5.1 (6-channel) audio subsystem support based on the Realtek*
ALC662 high definition audio codec
Onboard Intel
®
graphics subsystem with support for:
Analog displays (VGA)
Digital displays (DVI-I)
Flat Panel displays (LVDS interface)
Winbond* W83627DHG-P based Legacy I/O controller for hardware
management, serial, parallel, and PS/2* ports
Seven USB 2.0 ports:
Four back panel ports
Two ports are implemented with a dual port internal header for front panel
cabling
One port is implemented with an internal header (brown-colored) that
supports an Intel
®
Z-U130 USB Solid-State Drive or compatible device
Two Serial ATA (SATA) 3.0 Gb/s connectors (supporting IDE and AHCI mode)
One parallel port header
Two serial port connectors on the back panel
Two serial port headers
One PS/2-style keyboard port
One PS/2-style mouse port
Two Intel® 82574L Gigabit (10/100/1000 Mb/s) Ethernet LAN Controllers
including two RJ45 back panel connectors for dual LAN subsystems.
