3.2 Connectors and Headers
CAUTION
Only the following connectors/headers have overcurrent protection: Back panel and
front panel USB, VGA, serial, and PS/2.
The other internal connectors/headers are not overcurrent protected and should
peripherals. Do not use these connectors/headers to power devices external to the
. A fault in the load presented by the external devices could cause
damage to the computer, the power cable, and the external devices themselves.
NOTE
Computer systems that have an unshielded cable attached to a USB port may not meet
FCC Class B requirements, even if no device is attached to the cable. Use shielded
cable that meets the requirements for full-speed devices.
. The connectors and
headers can be divided into these groups:
Back panel I/O connectors (see page 47)
Component-side connectors and headers (see page 49)
