Embedded Intel® Atom Processor D2700 with Intel® NM10 Express Chipset 
23

NOTE
To be fully compliant with all applicable DDR3 SDRAM memory specifications, the
board should be populated with SO-DIMMs that support the Serial Presence Detect
(SPD) data structure. This allows the BIOS to read the SPD data and program the
chipset to accurately configure memory settings for optimum performance. If non-SPD
memory is installed, the BIOS will attempt to correctly configure the memory settings,
but performance and reliability may be impacted or the SO-DIMMs may not function
under the determined frequency.
Table 4 lists the supported SO-DIMM configurations.
Table 4. Supported Memory Configurations
1
Raw Card
Version
SO-DIMM
Capacity
DRAM Device
Technology
DRAM
Organization
# of DRAM
Devices
B
1 GB
1 Gb
128 M x 8
8
2 GB
2 Gb
256 M x 8
8
F
2 GB
1 Gb
128 M x 8
16
4 GB
2
2 Gb
256 M x 8
16
Notes:
1. System memory configurations are based on availability and are subject to change.
2. Support for one 4 GB SO-DIMM installed in slot 1. Slot 0 must be left empty.
