Embedded Intel® Atom
Processor
D2700
with Intel® NM10 Express C
hipset
51
3.2.2.1
Signal Tables for the C
onnectors and Headers
Table
12
. TPM Header
Pin
Signal Name
Pin
Signal Name
1
CK_33M_TPM_DIP
2
Ground
3
LFRAME#
4
Key (no pin)
5
PLTRST#
6
No connection
7
LAD3
8
LAD2
9
+3.3 V
10
LAD1
11
LAD0
12
Ground
13
No connection
14
No connection
15
+3.3 VSB
16
TPM_SERRQ
17
Ground
18
TPM_CLKRUN#
19
LPCPD#
20
No connection
Table
13
. Seri
al Port Headers
Pin
Signal Name
Pin
Signal Name
1
DCD (Data Carrier Detect)
2
RX
D# (Receive Data)
3
TXD# (Transmit Data)
4
DTR (Data Terminal Ready)
5
Ground
6
DSR (Data Set Ready)
7
RTS (Request To Send)
8
CTS (Clear To Send)
9
RI (Ring Indicator)
10
Key (no pin)
