Table 3 summarizes the resolution support of the graphics interfaces.
Table 3. Summary of the Resolution of the Graphics interfaces
2.5.1.2 Video
The Intel
®
Atom
TM
Processor D2700 supports the following video output functionalities
over its display interfaces:
(VLD/ iDCT/MC), WMV,
Fast video Composing, HW decode/ acceleration for MPEG4 Part 10 (AVC/H.264) & VC-
1; 720p60, 1080i60, 1080p@24 up to 20 Mps
Platform
H/W
No hardware assist for Flash Decode from Adobe 11.0 and onwards
D2700 processor supports Blu-Ray* 2.0 playback (Windows* only) - 1 x HD and 1 x SD
streaming
Video image Enhancement: Hue, Saturation, Brightness, Contrast (HSBC) adjust, Bob
De-Interlacing
2.6 System Memory
The board has two 204-pin DDR3 SO-DIMM sockets and supports the following
memory features:
DDR3 SDRAM SO-DIMMs with gold-plated contacts
Unbuffered, non-ECC, Raw Card B (1Rx8) and Raw Card-F (2Rx8) SO-DIMMs only
4 GB maximum total system memory
Minimum total system memory: 256 MB
Non-ECC DIMMs
Serial Presence Detect
DDR3 800 MHz and DDR3 1066 MHz SO-DIMMs (Higher speed SO-DIMMs
supported at 1066 MHz if supported by the memory module.)
When only using one SO-DIMM, DIMM 1 must be used
NOTE
Due to passively-cooled thermal constraints, system memory must have an operating
temperature rating of 85
o
C.
The board is designed to be passively cooled in a properly ventilated chassis. Chassis
venting locations are recommended above the system memory area for maximum heat
dissipation effectiveness.
