Embedded Intel® Atom Processor D2700 with Intel® NM10 Express Chipset 
38
2.13.1.2 Wake-up Devices and Events
Table 9 lists the devices or specific events that can wake the computer from specific
states.
Table 9. Wake-up Devices and Events
Devices/events that wake up the system…
…from this sleep state
Power switch
S3, S4, S5
(
Note 1)
RTC alarm
S3, S4, S5
(Note 1)
LAN
S3, S4, S5
(Note 1)
USB
S3
(Note 2)
WAKE#
S3, S4, S5
(Note 1)
PME# signal
S3, S4, S5
(Note 1)
Serial port
S3
PS/2 devices
S3, S4, S5
(Notes 1 and 3)
Notes:
1. S4 implies operating system support only.
2. USB ports must be turned off during S4/S5 states.
3. PS/2 wake from S5 should have a selection in the BIOS to enable wake from a combination key
(Alt + Print Screen) or the keyboard power button.

NOTE
The use of these wake-up events from an ACPI state requires an operating system that
provides full ACPI support. In addition, software, drivers, and peripherals must fully
support ACPI wake events.
