Embedded Intel® Atom
Processor
D2700
with Intel® NM10 Express C
hipset
53
Table
15
. Ba
cklight Inverter Vol
tage Selection Jumper
Voltage
Jumper Setting
Configuratio
n
3.3 V
2 and 4
Jumper position for 3.3 V (def
ault)
5 V
6 and 4
Jumper position for 5 V
12 V
3 and 4
Jumper position for 12 V
Table
16
. FPD Br
ightness Connector
Pin
Signal Name
Description
1
BKLT_EN
Backlight enable
2
BKLT_PWM
Backlight control
3
BKLT_PWR (5 V/12
V)
Backlight inverter power
4
BKLT_PWR (5 V/12
V)
Backlight inverter power
5
BKLT_GND/Brightness_GND
Ground (shared)
6
BKLT_GND/Brightness_GND
Ground (shared)
7
Brightness_Up
Panel brightness increase
8
Brightness_Down
Panel brightness decrease
Table
17
. Fla
t Panel Vol
tage Selection Jumper
Voltage
Jumper Setting
Configuration
5 V
1 and 2
Jumper position for 5 V (def
ault)
12 V
3 and 2
Jumper position for 12 V
