Embedded Intel® Atom
Processor
D2700
with Intel® NM10 Express C
hipset
58
3.2.2.3
Power Supply Connector
The board has a 2 x 12 power co
nnector (see Table
27
)
.
This board requires a TFX12V
or SFX12V power supply.
Table
27
. Power
Connector
Pin
Signal Name
Pin
Signal Name
1
+3.3 V
13
+3.3 V
2
+3.3 V
14
-
12 V
3
Ground
15
Ground
4
+5
V
16
PS
-ON# (power supply r
emote on/off)
5
Ground
17
Ground
6
+5 V
18
Ground
7
Ground
19
Ground
8
PWRGD (Power Good)
20
No connect
9
+5 V (Standby)
21
+5 V
10
+12 V
22
+5 V
11
+12 V
23
+5 V
12
No connect
24
Ground
Download from Www.Somanuals.com. All Manuals Search And Download.
