Intel Atom D2700 User Manual

Embedded Intel® Atom Processor D2700 with Intel® NM10 Express Chipset 
29
2.9.1 Serial Ports
The four serial ports (two back panel connectors and two internal headers) support
data transfers at speeds up to 115.2 kb/s with BIOS support.
For information about
Refer to
The location of the serial port connectors
Figure 9
2.9.2 Parallel Port
Use the BIOS Setup program to set the parallel port mode for the 25-pin D-Sub
parallel port header.
For information about
Refer to
The location of the parallel port connector
Figure 9
2.9.3 Keyboard and Mouse Interfaces
PS/2 keyboard and mouse connectors are located on the back panel.

NOTE
The keyboard is supported in the top PS/2 connector and the mouse is supported in
the bottom PS/2 connector. Power to the computer should be turned off before a
keyboard or mouse is connected or disconnected.
For information about
Refer to
The location of the keyboard and mouse connectors
Figure 9
