2.11 Audio Subsystem
The board supports the Intel
®
High Definition Audio (Intel
®
HD Audio) subsystem. The
audio subsystem consists of the following:
 Intel
®
NM10 Express Chipset
 Realtek* ALC662 audio codec
The audio subsystem has the following features:
 Advanced jack sense for the back panel audio jacks that enables the audio codec to
recognize the device that is connected to an audio port. The back panel audio jacks
are capable of re-
switched depending on the recognized device type.
 Front panel Intel
®
.
 3-port analog audio out stack.
 Windows Vista Basic certification.
 A signal-to-noise (S/N) ratio of 95 dB.
Table 6 lists the supported functions of the front panel and back panel audio jacks.
Table 6. Audio Jack Support
Audio Jack
Micro-
phone
Headphones
Line Out
(Front Spks)
Line In
(Stereo 2)
Mic-In
Front panel  Green
Default
Front panel  Pink
Default
Back panel  Blue
Default
Back panel  Green
(ctrl panel)
Default
Back panel  Pink
Default
