Embedded Intel® Atom
Processor
D2700
with Intel® NM10 Express C
hipset
55
Table
23
. Front Pa
nel USB
2.0
Headers
Pin
Signal Name
Pin
Signal Name
1
+5 VDC
2
+5 VDC
3
D-
4
D-
5
D+
6
D+
7
Ground
8
Ground
9
KEY (no pin)
10
No Connect
Table
24
.
Front Panel
USB Header
with Intel
®
Z-U130 USB
Solid-State Drive or
Compatible Device
Support
Pin
Signal Name
Pin
Signal Name
1
+5 VDC
2
NC
3
D-
4
NC
5
D+
6
NC
7
Ground
8
NC
9
KEY (no pin)
10
LED#
Table
25
. Inter
nal S/PDIF Head
er
Pin
Signal Name
Description
1
GND
Ground
2
SPDIF_OUT
S/PDIF signal from the codec
3
Key (no pin)
Key (no pin)
4
+5V_DC
5 V power
(for optical/TOSLINK module)
Download from Www.Somanuals.com. All Manuals Search And Download.
53
55
