Embedded Intel® Atom
Processor
D2700
with Intel® NM10 Express C
hipset
52
Table
14
. LVDS Da
ta Connector
Pin
Signal Name
Pin
Signal Name
1
EVEN_Lane3_P
21
N/C
2
EVEN_Lane3_N
22
EDID_3.3V
3
EVEN_Lane2_P
23
LCD_GND
4
EVEN_Lane2_N
24
LCD_GND
5
EVEN_Lane1_P
25
LCD_GND
6
EVEN_Lane1_N
26
EVEN_CLK_P
7
EVEN_Lane0_P
27
EVEN_CLK_N
8
EVEN_Lane0_N
28
BKLT_GND
9
ODD_Lane3_P
29
BKLT_GND
10
ODD_Lane3_N
30
BKLT_GND
11
ODD_Lane2_P
31
EDID_CLK
12
ODD_Lane2_N
32
BKLT_ENABLE
13
ODD_Lane1_P
33
BKLT_PWM_DIM
14
ODD_Lane1_N
34
ODD_CLK_P
15
ODD_Lane0_P
35
ODD_CLK_N
16
ODD_Lane0_N
36
BKLT_PWR (5V/12V/19V)
17
EDID_GND
37
BKLT_PWR (5V/12V/19V)
18
LCD_VCC (3.3V/5V/12V)
38
BKLT_PWR (5V/12V/19V)
19
LCD_VCC (3.3V/5V/12V)
39
N/C
20
LCD_VCC (3.3V/5V/12V)
40
EDID_DATA
