C H A P T E R 5 Managing the Switch
4 Click Close.
Tools for the Stack
Tools available for a stack When managing a stack, the following tools are available:
Stack Synchronization Manager
Purpose Before switches connected together via a Matrix Module can be man-
aged as a stack, their configurations must be synchronized. This man-
ager checks that all the configurations are compatible. The
configurations for all the switches are then synchronized from a spec-
ified switch.
Using the Synchronization
Manager
To start the Synchronization Manager:
1 Select Tools>Stack Synchronization Manager.
2 Follow the checks made and then click Switch Selection
and select the IP address for the switch with the configuration
that is to be copied to the other switches.
3 Click Next> to complete the synchronization of the switches.
