C H A P T E R 1 Intel Express 510T Switch
12
Connecting the Power
Introduction After connecting the devices to the switch, connect the power cable.
There are certain practical and safety considerations to be made be-
fore powering the switch on.
The Power Cable
Ground warning The switch is delivered with a power cable that fits the power sockets
in your country. If this is not the case, contact your dealer immediate-
ly and ask for the correct power cable.
Power cable wiring color
code
The wires in the power cable provided are color coded:
Important for UK use If the colors of the wires in the power cable provided do not corre-
spond with the markings that identify the terminals in your plug:
1 Make sure that the green and yellow wire is connected to the
terminal marked with the letter E, or with the ground symbol
, or is colored green and yellow.
2 Make sure that the blue wire is connected to the terminal
marked with the letter N or colored black.
3 Make sure that the brown wire is connected to the terminal
marked with the letter L or colored red.
Power supply to a rack If the switch is installed in a rack, make sure the rack’s power supply
socket has a ground connection and the rack is connected to a branch
supply or a power supply socket with a ground connection.
To avoid overloading the circuit and damaging the wiring of the pow-
er supply, the power supply to the rack must be adequate to cover the
extra power consumed by the switch.
Color Connection
Green and yellow Ground
Blue Neutral
Brown Live
500.book Page 12 Thursday, September 2, 1999 1:30 PM
