Intel Express 510T User Manual

38
C H A P T E R 2 Intel Device View
38
Diagnostic details window
This window provides comprehensive details of the error.
Trap Window
Traps window The Traps window displays all traps generated by the switch.
Color coding Traps are generated by the switch for many events, both normal and
errors. Traps displayed in Intel Device View are color coded accord-
ing to the severity of the trap.
Right mouse button
commands
Right click a message and Intel Device View offers:
Functions Description
Refresh Reloads and updates all the information in
this window.
Clear Clears all the messages displayed.
Properties Enables color coding to be switched on
and off and define maximum number of
messages displayed.
500.book Page 38 Thursday, September 2, 1999 1:30 PM
