100
C H A P T E R 6 Technical Specifications
100
Physical Specifications
Approvals The switch has the following approvals:
Physical The switch has the following physical specifications:
Approval for Standard
Safety UL 1950
CSA-C22.2 No. 950
IEC950
EN 60950
Emission FCC 47 CFR part 15 Class A
EN 55022 Class A
CISPR 22 Class A
VCCI Class 1 ITE
“C-Tick” Mark
CNS 13438 Class A
Susceptibility EN50082-1
IEC1000-4-2
IEC1000-4-3
IEC1000-4-4
IEC1000-4-5
CE Mark Yes
Specification Measurement
Dimensions Width: 17.35in. (441mm)
Height: 3.26in. (83mm)
Depth: 12.95in. (329mm)
Weight (approximate) 19lb. (8.6kg)
Recommended
clearance
Sides: 4.0in. (100mm)
Rear: 7.7in. (190mm)
500.book Page 100 Thursday, September 2, 1999 1:30 PM
