102
C H A P T E R 6 Technical Specifications
102
Power Specifications
Consumption Power consumption: 100W maximum
Power supply The power supply has:
Performance Specifications
MAC addresses The number of MAC addresses:
Throughput Internal backplane bandwidth: 2.1Gbps
CPU IDT 79R3041 (16 MHz)
Nominal power supply
voltages
100 to 120 V AC, 2.5A
200 to 240 V AC, 1.5A
Class 1 protective ground
Voltage range 90 to 135 V
180 to 265 V
Frequency 47 to 63 Hz
Main power connection Detachable power cable
Input protection Non-replaceable, internal fuse
MAC
addresses per
port
Number of ports
available for multiple
addresses
Max 8000 All
500.book Page 102 Thursday, September 2, 1999 1:30 PM
