Intel NUC5i5MYBE User Manual

13
1 Product Description
1.1 Overview
1.1.1 Feature Summary
Table 1 summarizes the major features of Intel® NUC Board NUC5i5MYBE.
Table 1. Feature Summary
Form Factor
4.0 inches by 4.0 inches (101.60 millimeters by 101.60 millimeters)
Processor
• Intel® NUC Board NUC5i5MYBE has a soldered-down 5
th
generation Intel® Core™ i5-
5300U dual-core processor with up to 15 W TDP
― Integrated graphics
― Integrated memory controller
― Integrated PCH
Memory
• Two 204-pin DDR3L SDRAM Small Outline Dual Inline Memory Module (SO-DIMM)
sockets
• Support for DDR3L 1600/1333 MHz SO-DIMMs
• Support for 2 Gb and 4 Gb memory technology
• Support for up to 16 GB of system memory with two SO-DIMMs using 4 Gb memory
technology
• Support for non-ECC memory
• Support for 1.35 V low voltage JEDEC memory only
Graphics
• Integrated graphics support for processors with Intel® Graphics Technology:
• Two Mini DisplayPort* back panel connectors
• Flat panel displays via the internal Embedded DisplayPort* (eDP) connector
Audio
• Intel® High Definition (Intel® HD) Audio via the Mini DisplayPort 1.2 interfaces through the
processor
• Realtek HD Audio via a stereo microphone/headphone 3.5 mm jack on the front panel
Storage
• SATA ports:
― One SATA 6.0 Gb/s port (blue)
― One SATA 6.0 Gb/s port is reserved for an M.2 2280 Module
• Note: Intel® NUC Board NUC5i5MYBE supports key type B (PCI Express x1/x2/SATA)
Peripheral Interfaces
• USB 3.0 ports:
― Two ports are implemented with external front panel connectors (blue)
― Two ports are implemented with external back panel connectors (blue)
• USB 2.0 ports:
― Two ports via one dual-port internal 1x8 1.25 mm pitch header (white)
― One port is reserved for an M.2 2280 Module
― One port is reserved for an M.2 2230 Module
continued
