Intel NUC Board NUC5i5MYBE Technical Product Specification
24
DisplayPort output supports Multi-Stream Transport (MST) which allows for multiple
independent video streams (daisy-chain connection with multiple monitors) over a single
DisplayPort. This will require the use of displays that support DisplayPort 1.2 and allow for this
feature.
For information about Refer to
DisplayPort technology http://www.displayport.org
1.5.1.3.1 DisplayPort 1.2 Multi-Stream Transport Daisy-Chaining
Table 5 lists the maximum resolutions available when using DisplayPort 1.2 Multi-Stream
Transport.
Table 5. DisplayPort Multi-Streaming Resolutions
DisplayPort Usage Models
Monitor 1
Monitor 2
Monitor 3
3 Monitors 1920 x 1200 @ 60 Hz 1920 x 1080 @ 60 Hz 1920 x 1080 @ 60 Hz
2 Monitors
2560 x 1600 @ 60 Hz
2560 x 1600 @ 60 Hz
3 Monitors
(with DisplayPort 1.2 hub)
1920 x 1080 @ 60 Hz
1920 x 1080 @ 60 Hz
1920 x 1080 @ 60 Hz
1.5.1.4 Multiple DisplayPort Configurations
Multiple DisplayPort configurations feature the following:
• Three independent displays
• Dual DisplayPort 1.2 with 4K support
• Collage Display
Table 6. Multiple Display Configuration Maximum Resolutions
Display 1 Display 2 Display 3
Maximum
Resolution
Display 1
Maximum
Resolution
Display 2
Maximum
Resolution
Display 3
DP DP eDP 3840 x 2160 @ 60 Hz 2880 x 1800 @ 60 Hz
Note: In order to achieve higher resolutions and frequencies, cables and monitors must meet DisplayPort 1.2
specifications. Maximum resolution given is for HBR2 (High Bit Rate 2) Link Data Rate. Requires a monitor that
supports HBR2.
For information about Refer to
Multiple display maximum
resolutions
https://www-
ssl.intel.com/content/www/us/en/processors/core/CoreTechnicalResources.html (Generic
link)
TBD (Specific Link)
