Intel NUC5i5MYBE User Manual

Technical Reference
69
Table 34. Power Budget for Assessing the DC-to-DC Circuit’s Power Rating (worst case:
Embedded board in 3
rd
party chassis)
NUC5i5MYBE/NUC5i3MYBE
(3
rd
party chassis) Max Power Rating (W) Power Req
(Note)
(W)
15 W SoC 15 18.75
2 X 8 GB DDR3L 7.83 9.78
4 x USB3 (std 900mA) ports 18 22.5
2 x USB2 (std 500mA) header 5 6.25
M.2 2280 module 8.25 10.3125
M.2 2230 module 6.6 8.25
SATA Power 10 12.5
LAN, video, audio, other 3.14 3.925
Low Speed Custom Solutions 16.6 20.75
miniDP 3.3 4.125
FAN 2.5 3.125
eDP 14 17.5
Note: Power requirements estimated at 80% efficiency (combined AC adapter + DC-to-DC/VR).
