Intel NUC5i5MYBE User Manual

Product Description
33
1.9.1 Audio Subsystem Software
Audio software and drivers are available from Intel’s World Wide Web site.
For information about
Refer to
Obtaining Audio software and drivers http://downloadcenter.intel.com
1.10 LAN Subsystem
The LAN subsystem consists of the following:
• Intel I218LM Gigabit Ethernet Controller (10/100/1000 Mb/s)
• RJ-45 LAN connector with integrated status LEDs
Additional features of the LAN subsystem include:
• CSMA/CD protocol engine
• LAN connect interface between the Processor and the LAN controller
• Power management capabilities
 ACPI technology support
 LAN wake capabilities
• LAN subsystem software
For information about
Refer to
LAN software and drivers http://downloadcenter.intel.com
1.10.1 Intel® I218LM Gigabit Ethernet Controller
The Intel I218LM Gigabit Ethernet Controller supports the following features:
• Compliant with the 1 Gb/s Ethernet 802.3, 802.3u, 802.3z, 802.3ab specifications
• Multi-speed operation: 10/100/1000 Mb/s
• Full-duplex operation at 10/100/1000 Mb/s; Half-duplex operation at 10/100 Mb/s
• Flow control support compliant with the 802.3X specification as well as the specific operation
of asymmetrical flow control defined by 802.3z
• VLAN support compliant with the 802.3q specification
• Supports Jumbo Frames (up to 9 kB)
 IEEE 1588 supports (Precision Time protocol)
• MAC address filters: perfect match unicast filters, multicast hash filtering, broadcast filter, and
promiscuous mode
1.10.2 LAN Subsystem Software
LAN software and drivers are available from Intel’s World Wide Web site.
For information about Refer to
Obtaining LAN software and drivers
http://downloadcenter.intel.com

Intel NUC5i5MYBE Specifications

General

Brand	Intel
Model	NUC5i5MYBE
Category	Motherboard
Language	English
