Intel NUC Board NUC5i5MYBE Technical Product Specification
56
Table 25. Low Speed Custom Solutions Header
Pin
Signal Name
Pin
Signal Name
1
Reserved
2
GND
3
Reserved
4
DMIC_CLK
5 3.3 Vsby ± 5% (1.3A) 6 DMIC_DATA
7
Key (no pin)
8
SMB_ALERT#/GPIO11
9
5 Vsby ± 5% (2.0A)
10
SCI_SMI_IO/PCH_GPIO44
11
PCH_GPIO24
12
DirectApp Launch/PCH_GPIO14
13 I2C0_SCL/SIO_GPIO5 14 I2C0_SDA/SIO_GPIO5
15
I2C1_SCL (shared w/M.2)/SIO_GPIO7
16
I2C1_SDA (shared w/M.2)/SIO_GPIO6
17
SMB_CLK
18
SMB_DATA
NOTE
To enable alternate GPIO functions, GPIO Lockdown must first be disabled in the system BIOS.
Table 26. High Speed Custom Solutions Connector (PCIe x 4, SATA)
Pin
Signal
1 SATA_RXP
2 SATA_RXN
3 GND
4
SATA_TXP
5
SATA_TXN
6
GND
7
RESERVED
8
RESERVED
9
PERST# (O)(0/3.3V)
10
PEWAKE# (I/O)(0/3.3V)
11
CLKREQ# (I/O)(0/3.3V)
12 RESERVED
13 RESERVED
14
GND
15
PERp5_L3
16
PERn5_L3
17
GND
18
PETp5_L3
19
PETn5_L3
20
GND
21
PERp5_L2
22 PERn5_L2
23 GND
24
PETp5_L2
continued
