Intel NUC5i5MYBE User Manual

Technical Reference
55
Table 22. 30-Pin eDP Connector
Pin
Signal Name
Pin
Signal Name
1
NC_Reserved
16
LCD_GND
2
High-speed_GND
17
HPD (DDPD_HPD)
3 Lane1_N (DDPD_[1]N) 18 BKLT_GND
4
Lane1_P (DDPD_[1]P)
19
BKLT_GND
5
High-speed_GND
20
BKLT_GND
6
Lane0_N (DDPD_[0]N)
21
BKLT_GND
7 Lane0_P (DDPD_[0]P) 22 BKLT_ENABLE
8
High-speed_GND
23
BKLT_PWM_DIM
9
AUX_CH_P (DDPD_AUXP)
24
NC_Reserved
10
AUX_CH_N (DDPD_AUXN)
25
NC_Reserved
11 High-speed_GND 26 BKLT_PWR
12
LCD_VCC
27
BKLT_PWR
13
LCD_VCC
28
BKLT_PWR
14
LCD_Self_Test-or-NC
29
BKLT_PWR
15 LCD_GND 30 NC_Reserved
NOTE
Connector used is JAE FI-X30SSLA-HF two-lane, 1x30 eDP connector.
Table 23. Flat Panel Voltage Selection Header
Pin
Signal Name
1
Key
2
3.3 Vsby ± 5% (1.3A)
3 (Vin) 19V ± 5% (2.0A)
4
LCD_VCC
5
Key
6
5 Vsby ± 5% (2.0A)
Table 24. Backlight Inverter Voltage Selection Header
Pin
Signal Name
1
5 V ± 5% (1.3A)
2 BKLT_PWR
3
(Vin) 19V ± 5% (2.0A)
