Intel NUC Board NUC5i5MYBE Technical Product Specification
54
Table 21. M.2 2230 Module (Mechanical Key E) Connector (continued)
Pin
Signal Name
Pin
Signal Name
60
I2C CLK (O)(0/3.3)
61
RESERVED
58
I2C DATA (I/O)(0/3.3)
59
RESERVED
56 W_DISABLE1# (O)(0/3.3V) 57 GND
54
W_DISABLE2# (O)(0/3.3V)
55
PEWAKE0# (I/O)(0/3.3V)
52
PERST0# (O)(0/3.3V)
53
CLKREQ0# (I/O)(0/3.3V)
50
SUSCLK(32kHz) (O)(0/3.3V)
51
GND
48 RESERVED 49 REFCLKN0
46
RESERVED
47
REFCLKP0
44
RESERVED
45
GND
42
C-Link CLK (I/O)
43
PERn0
40 C-Link DATA (I/O) 41 PERp0
38
C-Link RESET (I) (0/3.3V)
39
GND
36
RESERVED
37
PETn0
34
RESERVED
35
PETp0
32 RESERVED 33 GND
30
Connector Key
31
Connector Key
28
Connector Key
29
Connector Key
26
Connector Key
27
Connector Key
24 Connector Key 25 Connector Key
22
RESERVED
23
RESERVED
20
RESERVED
21
RESERVED
18
GND
19
RESERVED
16 RESERVED 17 RESERVED
14
RESERVED
15
RESERVED
12
RESERVED
13
RESERVED
10
RESERVED
11
RESERVED
8 RESERVED 9 RESERVED
6
RESERVED
7
GND
4
3.3V
5
USB_D-
2
3.3V
3
USB_D+
1 GND
