Intel NUC5i5MYBE User Manual

Technical Reference
53
Table 20. M.2 2280 Module (Mechanical Key B) (continued)
Pin
Signal Name
Pin
Signal Name
54
PEWAKE# (I/O)(0/3.3V)
55
REFCLKP
52
CLKREQ# (I/O)(0/3.3V)
53
REFCLKN
50 PERST# (O)(0/3.3V) 51 GND
48
N/C
49
PETp0/SATA-A+
46
N/C
47
PETn0/SATA-A-
44
N/C
45
GND
42 N/C 43 PERp0/SATA-B-
40
N/C
41
PERn0/SATA-B+
38
DEVSLP (O)
39
GND
36
N/C
37
PETp1
34 N/C 35 PETn1
32
N/C
33
GND
30
N/C
31
PERp1
28
N/C
29
PERn1
26 N/C 27 GND
24
N/C
25
N/C
22
N/C
23
N/C
20
N/C
21
CONFIG_0
18 Connector Key 19 Connector Key
16
Connector Key
17
Connector Key
14
Connector Key
15
Connector Key
12
Connector Key
13
Connector Key
10 DAS/DSS# (I/O) 11 GND
8
N/C
9
USB_D-
6
N/C
7
USB_D+
4
3.3V
5
GND
2 3.3V 3 GND
1
CONFIG_3
Table 21. M.2 2230 Module (Mechanical Key E) Connector
Pin
Signal Name
Pin
Signal Name
74 3.3V 75 GND
72
3.3V
73
RESERVED
70
RESERVED
71
RESERVED
68
RESERVED
69
GND
66 RESERVED 67 RESERVED
64
RESERVED
65
RESERVED
62
ALERT# (I)(0/3.3)
63
GND
continued
