Intel NUC Board NUC5i5MYBE Technical Product Specification

2.2.4 Connectors and Headers (Bottom)

Figure 14 shows the locations of the connectors and headers on the bottom-side of the board.

Figure 14. Connectors and Headers (Bottom)
