Intel NUC5i5MYBE

To Next Page

To Previous Page

Product Description

Figure 6 shows the flat panel connectors on the top-side of the board.

Item

Description

A Flat panel voltage selection header

B Embedded DisplayPort connector

Figure 6. Flat Panel Connectors on Top-side of the Board
