Intel NUC Board NUC5i5MYBE Technical Product Specification
52
2.2.4.1 Signal Tables for the Connectors and Headers
Table 18. SATA Power Header (1.25 mm pitch)
Pin
Signal Name
1 5 V
2 5 V
3 3.3 V
4 GND
5 GND
NOTE
Connector is Molex part number 53398-0571, 1.25mm Pitch PicoBlade* Header, Surface Mount,
Vertical, Lead-Free, 5 Circuits.
Table 19. Dual-Port Internal USB 2.0 Header (1.25 mm pitch)
Pin
Signal Name
Pin
Signal Name
1
+5 V DC
2
Data (negative)
3
Data (positive)
4
Ground
5 Ground 6 Data (positive)
7
Data (negative)
8
+5 V DC
NOTE
Connector is Molex part number 53398-0871, 1.25mm Pitch PicoBlade Header, Surface Mount,
Vertical, Lead-Free, 8 Circuits.
Table 20. M.2 2280 Module (Mechanical Key B) Connector
Pin
Signal Name
Pin
Signal Name
74
3.3V
75
CONFIG_2
72 3.3V 73 GND
70
3.3V
71
GND
68
SUSCLK(32kHz) (O)(0/3.3V)
69
CONFIG_1
66
N/C
67
N/C
64 N/C 65 N/C
62
N/C
63
N/C
60
N/C
61
N/C
58
N/C
59
N/C
56 N/C 57 GND
continued
