Intel NUC5i5MYBE User Manual

Intel NUC Board NUC5i5MYBE Technical Product Specification
18
Table 3. Components Shown in Figure 2
Item from
Figure 2 Description
A
Back panel connectors
B Backlight inverter voltage selection header
C
High Speed Custom Solutions connector (PCIe x4, SATA)
D
Serial port header
E
M.2 2230 Module connector
F SATA power connector
G
M.2 2280 Module connector
H
Front panel dual-port USB 2.0 header (1.25 mm pitch)
I
Front panel USB 3.0 connector
J SATA Disk-on-Module (DOM) voltage selection header
K
Front panel USB 3.0 connector
L
SATA 6.0 Gb/s connector
M
Front panel stereo microphone/headphone jack
N BIOS security jumper
O
Intel® Management Engine BIOS Extension (Intel® MEBX) Reset header
P
DDR3L SO-DIMM 1 socket
Q
DDR3L SO-DIMM 2 socket

Intel NUC5i5MYBE Specifications

General

Brand	Intel
Model	NUC5i5MYBE
Category	Motherboard
Language	English
