Intel NUC5i5MYBE User Manual

iii
Board Identification Information
Basic Intel® NUC Board NUC5i5MYBE Identification Information
AA Revision
BIOS Revision
Notes
H47797-202 MYBDWi5v.86A.0012 1,2
Notes:
1. The AA number is found on a small label on the component side of the board.
2. The Intel
®
Core™ i5-5300U processor is used on this AA revision consisting of the following component:
Device
Stepping
S-Spec Numbers
Intel Core i5-5300U
F0
SR23X
Specification Changes or Clarifications
The table below indicates the Specification Changes or Specification Clarifications that apply to
the Intel NUC Board NUC5i5MYBE.
Specification Changes or Clarifications
Date
Type of Change
Description of Changes or Clarifications
February 2015
Spec Change
• Updated Figure 5 to show correct pin numbering for the Backlight Inverter
Voltage Selection header.
• Updated Figure 20 and added a Note to address the MEBX_Reset header
non-conductive protective cap.
• Added additional information regarding the Low Speed Custom Solutions
Header.
May 2015 Spec Clarification
• Updated the Note under Table 22 to clarify the connector used.
• Updated the 3
rd
Warning in Section 2.7 to correct the cross-reference from
Section 2.8 to Section 2.9.
June 2015 Spec Clarification
• Updates made to the Note under Table 19, the Note under Table 22, and
Section 2.2.4.7.
August 2015
Spec Clarification
• Deleted ST Micro as a source for TPM 2.0 in Section 1.13.1.6.
• Added Table 34. Power Budget for Assessing the DC-to-DC Circuit’s Power
Rating (worst case: Embedded board in 3rd party chassis)
May 2016
Spec Change
• Deleted the Near Field Communication (NFC) header and all related text.
• Clarified the Note in Section 1.13.1.6 regarding TPM 2.0.
January 2017
Spec Changes
• Deleted references to Integrator Toolkit, including the section “Custom
Splash Screen”
May 2017
Spec Change
• Remove reference to "RAID 0 auto replace" in the Intel® Rapid Storage
Technology / SATA RAID section.
Errata
Current characterized errata, if any, are documented in a separate Specification Update. See
http://www.intel.com/content/www/us/en/nuc/overview.html
for the latest documentation.

Intel NUC5i5MYBE Specifications

General

Brand	Intel
Model	NUC5i5MYBE
Category	Motherboard
Language	English
