Intel® Server Board S2400SC TPS On-board Connector/Header Overview
Revision 2.0 Intel order number G36516-002
89
Connector
Quantity
Reference Designators
Connector Type
Pin Count
IPMB
1
J1J3
Header
4
Configuration
jumpers
6
J1C4 (BMC Force Update), J1C5 (BIOS Recovery
),
J2J3 (BIOS Default), J2J2 (ME Force Update),
J2J6 (Password Clear), J2J4 (CPLD Update)
Jumper 3
TPM
1
J4J1
Connector
14
8.2
Power Connectors
The main power supply connection uses an SSI-compliant 2x12 pin connector (J1H3).
Three additional power-related connectors also exist:
 Two SSI-compliant 2x4 pin power connectors (J9A1, J9K1) to provide 12-V power to the
CPU voltage regulators and memory.
 One SSI-compliant 1x5 pin connector (J9K2) to provide I
2
C monitoring of the power
supply.
The following tables define these connector pin-outs:
Table 23. Main Power Connector Pin-out (J1H3)
Pin
Signal
Color
Pin
Signal
Color
1
+3.3 Vdc
Orange
13
+3.3 Vdc
Orange
2
+3.3 Vdc
Orange
14
-12 Vdc
Blue
3
GND
Black
15
GND
Black
4
+5 Vdc
Red
16
PS_ON#
Green
5
GND
Black
17
GND
Black
6
+5 Vdc
Red
18
GND
Black
7
GND
Black
19
GND
Black
8
PWR_OK
Gray
20
NC
White
9
5 VSB
Purple
21
+5 Vdc
Red
10
+12 Vdc
Yellow
22
+5 Vdc
Red
11
+12 Vdc
Yellow
23
+5 Vdc
Red
12
+3.3 Vdc
Orange
24
GND
Black
Table 24. CPU 1/CPU 2 Power Connector Pin-out (J5J2, J8A1)
Pin
Signal
Color
1
GND of Pin 5
Black
2
GND of Pin 6
Black
3
GND of Pin 7
Black
4
GND of Pin 8
Black
5
+12 Vdc CPU1
Yellow/black
6
+12 Vdc CPU1
Yellow/black
7
+12 Vdc
DDR3_CPU1
Yellow/black
8
+12 Vdc
DDR3_CPU1
Yellow/black
Table 25. Power Supply Auxiliary Signal Connector Pin-out (J1J2)
Pin
Signal
Color
1
SMB_CLK_FP_PWR_R
Orange
2
SMB_DAT_FP_PWR_R
Black
