On-board Connector/Header Overview Intel® Server Board S2400SC TPS
Intel order number G36516-002 Revision 2.0
90
Pin
Signal
Color
3
SMB_ALRT_3_ESB_R
Red
4
3.3 V SENSE-
Yellow
5
3.3 V SENSE+
Green
8.3
System Management Headers
8.3.1
Intel
®
Remote Management Module 4 Connector
A 30-pin Intel
®
RMM4 connector (J1C7) and a 7-pin Intel
®
RMM4 Lite connector (J3D1) are
included on the server board to support the optional Intel
®
Remote Management Module 4 or
Intel
®
Remote Management Module 4 Lite. This server board does not support third-party
management cards.
Note: This connector is not compatible with the previous generation Intel
®
Remote Management
Modules (Intel
®
RMM/RMM2/RMM3)
Table 26. Intel
®
RMM4 Connector Pin-out (J1C7)
Pin
Signal Name
Pin
Signal Name
1
3V3_AUX
2
MDIO
3
3V3_AUX
4
MDC
5
GND
6
TXD_0
7
GND
8
TXD_1
9
GND
10
TXD_2
11
GND
12
TXD_3
13
GND
14
TX_CTL
15
GND
16
RX_CTL
17
GND
18
RXD_0
19
GND
20
RXD_1
21
GND
22
RXD_2
23 GND 24
RXD_3
25
GND
26
TX_CLK
27
GND
28
RX_CLK
29
GND
30
PRESENT#
Table 27. Intel
®
RMM4 – Lite Connector Pin-out (J3D1)
Pin
Signal Name
Pin
Signal Name
1
3V3_AUX
2
SPI_RMM4_LITE_DI
3
N/A
4
SPI_RMM4_LITE_CLK
5
SPI_RMM4_LITE_DO
6
GND
7
SPI_RMM4_LITE_CS_N
8
GND
8.3.2
TPM connector
Table 28. TPM connector Pin-out (J4J1)
Pin
Signal Name
Pin
Signal Name
1
No pin
2
LPC_LAD<1>
3
LPC_LAD<0>
4
GND
5
IRQ_SERIAL
6
LPC_FRAME_N
7
P3V3
8
GND
9
RST_IBMC_NIC_N
10
CLK_33M_TPM_CONN
