Intel® Server Board S2400SC TPS System Security
Revision 2.0 Intel order number G36516-002 49
4.2.3.1 Security Screen
To enter the BIOS Setup, press the F2 function key during boot time when the OEM or Intel logo
displays. The following message displays on the diagnostics screen and under the Quiet Boot
logo screen:
Press <F2> to enter setup
When the Setup is entered, the Main screen displays. The BIOS Setup utility provides the
Security screen to enable and set the user and administrative passwords and to lock out the
front panel buttons so they cannot be used. The Intel
®
Server Board S5520URT provides TPM
settings through the security screen.
To access this screen from the Main screen, select the Security option.
Main
Advanced
Security
Server Management
Boot Options
Boot Manager
Administrator Password Status
<Installed/Not Installed>
User Password Status
<Installed/Not Installed>
Set Administrator Password [1234aBcD]
Set User Password [1234aBcD]
Front Panel Lockout Enabled/
Disabled
TPM State
<Enabled & Activated/Enabled & Deactivated/Disabled &
Activated/Disabled & Deactivated>
TPM Administrative Control
No Operation/
Turn On/Turn Off/Clear Ownership
Figure 19. Setup Utility – TPM Configuration Screen
