Intel® Server Board S2400SC TPS Intel® Light Guided Diagnostics
Revision 2.0 Intel order number G36516-002
107
Color
State
Criticality
Description
(indicates not enough power supplies present)
 In non-sparing and non-mirroring mode if the threshold of
correctable errors is crossed within the window
 Correctable memory error threshold has been reached for a failing
DDR3 DIMM when the system is operating in a non-redundant
mode
Amber
Solid on
Critical, non-
recoverable –
System is halted

Fatal alarm – system has failed or shutdown:
 CPU CATERR signal asserted
 MSID mismatch detected (CATERR also asserts for this case).
 CPU 1 is missing
 CPU Thermal Trip
 No power good – power fault
 DIMM failure when there is only 1 DIMM present and hence no
good memory present.
 Runtime memory uncorrectable error in non-redundant mode.
 DIMM Thermal Trip or equivalent
 SSB Thermal Trip or equivalent
 CPU ERR2 signal asserted
 BMC\Video memory test failed. (Chassis ID shows blue/solid-on for
this condition)
 Both uBoot BMC FW images are bad. (Chassis ID shows
blue/solid-on for this condition)
 240VA fault
 Fatal Error in processor initialization:
 Processor family not identical
 Processor model not identical
 Processor core/thread counts not identical
 Processor cache size not identical
 Unable to synchronize processor frequency
 Unable to synchronize QPI link frequency
