Intel® Server Board S2400SC TPS Appendix B: Integrated BMC Sensor Tables
Revision 2.0 Intel order number G36516-002
125
Full Sensor Name
(Sensor name in SDR)
Sensor
#
Platform
Applicability
Sensor Type
Event/Reading
Type
Event Offset Triggers
Contrib. To
System Status
Assert/De-
assert
Readable
Value/Off
sets
Event
Data
Rearm
Stand-
by
Processor 2 Thermal Margin
(P2 Therm Margin)
75h All
Temperatur
e
01h
Threshold
01h
- - - Analog R, T A –
Processor 3 Thermal Margin
(P3 Therm Margin)
76h
Platform-
specific
Temperatur
e
01h
Threshold
01h
- - - Analog R, T A –
Processor 4 Thermal Margin
(P4 Therm Margin)
77h
Platform-
specific
Temperatur
e
01h
Threshold
01h
- - - Analog R, T A –
Processor 1 Thermal
Control %
(P1 Therm Ctrl %)
78h All
Temperatur
e
01h
Threshold
01h
[u] [c,nc]
nc =
Degraded
c = Non-fatal
As and
De
Analog
Trig
Offset
A –
Processor 2 Thermal
Control %
(P2 Therm Ctrl %)
79h All
Temperatur
e
01h
Threshold
01h
[u] [c,nc]
nc =
Degraded
c = Non-fatal
As and
De
Analog
Trig
Offset
A –
Processor 3 Thermal
Control %
(P3 Therm Ctrl %)
7Ah
Platform-
specific
Temperatur
e
01h
Threshold
01h
[u] [c,nc]
nc =
Degraded
c = Non-fatal
As and
De
Analog
Trig
Offset
A –
Processor 4 Thermal
Control %
(P4 Therm Ctrl %)
7Bh
Platform-
specific
Temperatur
e
01h
Threshold
01h
[u] [c,nc]
nc =
Degraded
c = Non-fatal
As and
De
Analog
Trig
Offset
A –
Processor 1 ERR2 Timeout
(P1 ERR2)
7Ch All
Processor
07h
Digital
Discrete
03h
01 – State Asserted fatal
As and
De
–
Trig
Offset
A –
Processor 2 ERR2 Timeout
(P2 ERR2)
7Dh All
Processor
07h
Digital
Discrete
03h
01 – State Asserted fatal
As and
De
–
Trig
Offset
A –
Processor 3 ERR2 Timeout
(P3 ERR2)
7Eh
Platform-
specific
Processor
07h
Digital
Discrete
03h
01 – State Asserted fatal
As and
De
–
Trig
Offset
A –
