Appendix B: Integrated BMC Sensor Tables Intel® Server Board S2400SC TPS
Intel order number G36516-002 Revision 2.0
Full Sensor Name
(Sensor name in SDR)
Contrib. To
System Status
Hot 2-3
(P4 Mem23 VRD Hot)
9Bh All
e
01h
Discrete
05h
01 - Limit exceeded Non-fatal
As and
De
–
Trig
Offset
A –
Tachometer 1
(PS1 Fan Tach 1)
A0h
Chassis-
specific
Fan
04h
Generic –
digital discrete
01 – State Asserted Non-fatal
As and
De
-
Trig
Offset
M -
Tachometer 2
(PS1 Fan Tach 2)
A1h
Chassis-
specific
Fan
04h
Generic –
digital discrete
01 – State Asserted Non-fatal
As and
De
-
Trig
Offset
M -
Tachometer 1
(PS2 Fan Tach 1)
A4h
Chassis-
specific
Fan
04h
Generic –
digital discrete
01 – State Asserted Non-fatal
As and
De
-
Trig
Offset
M -
Tachometer 2
(PS2 Fan Tach 2)
A5h
Chassis-
specific
Fan
04h
Generic –
digital discrete
01 – State Asserted Non-fatal
As and
De
-
Trig
Offset
M -
Processor 1 DIMM Aggregate
Thermal Margin 1
(P1 DIMM Thrm Mrgn1)
B0h All
e
01h
Threshold
01h
[u,l] [c,nc]
Degraded
c = Non-fatal
As and
De
Analog R, T A –
Processor 1 DIMM Aggregate
Thermal Margin 2
(P1 DIMM Thrm Mrgn2)
B1h All
e
01h
Threshold
01h
[u,l] [c,nc]
Degraded
c = Non-fatal
As and
De
Analog R, T A –
Processor 2 DIMM Aggregate
Thermal Margin 1
(P2 DIMM Thrm Mrgn1)
B2h All
e
01h
Threshold
01h
[u,l] [c,nc]
Degraded
c = Non-fatal
As and
De
Analog R, T A –
Processor 2 DIMM Aggregate
Thermal Margin 2
(P2 DIMM Thrm Mrgn2)
B3h All
e
01h
Threshold
01h
[u,l] [c,nc]
Degraded
c = Non-fatal
As and
De
Analog R, T A –
Processor 3 DIMM Aggregate
Thermal Margin 1
(P3 DIMM Thrm Mrgn1)
B4h
Platform
Specific
e
01h
Threshold
01h
[u,l] [c,nc]
Degraded
c = Non-fatal
As and
De
Analog R, T A –
