Intel® Xeon® Processor E5-2600 Product Family Uncore Performance Monitoring
56 Reference Number: 327043-001
TRACKER_INSERTS
• Title: Tracker Allocations
• Category: TRACKER Events
• Event Code: 0x06
• Max. Inc/Cyc: 1, Register Restrictions: 0-3
• Definition: Counts the number of allocations into the local HA tracker pool. This can be used in
conjunction with the occupancy accumulation event in order to calculate average latency. One can-
not filter between reads and writes. HA trackers are allocated as soon as a request enters the HA
and is released after the snoop response and data return (or post in the case of a write) and the
response is returned on the ring.
TxR_AD
• Title: Outbound NDR Ring Transactions
• Category: OUTBOUND_TX Events
• Event Code: 0x0F
• Max. Inc/Cyc: 1, Register Restrictions: 0-3
• Definition: Counts the number of outbound transactions on the AD ring. This can be filtered by
the NDR and SNP message classes. See the filter descriptions for more details.
TxR_AD_CYCLES_FULL
• Title: AD Egress Full
• Category: AD_EGRESS Events
• Event Code: 0x2A
• Max. Inc/Cyc: 1, Register Restrictions: 0-3
• Definition: AD Egress Full
REGION10 bxxxxx1xx TAD Region 10:
Filters request made to TAD Region 10
REGION11 bxxxx1xxx TAD Region 11:
Filters request made to TAD Region 11
Table 2-52. Unit Masks for TRACKER_INSERTS
Extension
umask
[15:8]
Description
ALL b00000011 All Requests:
Requests coming from both local and remote sockets.
Table 2-53. Unit Masks for TxR_AD
Extension
umask
[15:8]
Description
NDR bxxxxxxx1 Non-data Responses:
Filter for outbound NDR transactions sent on the AD ring. NDR
stands for "non-data response" and is generally used for completions
that do not include data. AD NDR is used for transactions to remote
sockets.
SNP bxxxxxx1x Snoops:
Filter for outbound SNP transactions sent on the ring. These
transactions are generally snoops being sent out to either remote or
local caching agents. This should be zero if Early Snoop is enabled.
Table 2-51. Unit Masks for TAD_REQUESTS_G1 (Sheet 2 of 2)
Extension
umask
[15:8]
Description
