Intel Xeon E5-2600 Series - Q_Py_Pci_Pmon_Pkt_Match1 Registers; Q_Py_Pci_Pmon_Pkt_Match0 Registers

Reference Number: 327043-001 91
Intel® Xeon® Processor E5-2600 Product Family Uncore Performance Monitoring
Table 2-88. Q_Py_PCI_PMON_PKT_MATCH1 Registers
Field Bits
HW
Reset
Val
Description
--- 31:20 0x0 Reserved; Must write to 0 else behavior is undefined.
RDS 19:16 0x0 Response Data State (valid when MC == DRS and Opcode == 0x0-
2). Bit settings are mutually exclusive.
b1000 - Modified
b0100 - Exclusive
b0010 - Shared
b0001 - Forwarding
b0000 - Invalid (Non-Coherent)
--- 15:4 0x0 Reserved; Must write to 0 else behavior is undefined.
RNID_3_0 3:0 0x0 Remote Node ID(3:0 - Leat Significant Bits)
Table 2-89. Q_Py_PCI_PMON_PKT_MATCH0 Registers
Field Bits
HW
Reset
Val
Description
RNID_4 31 0x0 Remote Node ID(Bit 4 - Most Significant Bit)
--- 30:18 0x0 Reserved; Must write to 0 else behavior is undefined.
DNID 17:13 0x0 Destination Node ID
MC 12:9 0x0 Message Class
b0000 HOM - Requests
b0001 HOM - Responses
b0010 NDR
b0011 SNP
b0100 NCS
---
b1100 NCB
---
b1110 DRS
OPC 8:5 0x0 Opcode
DRS,NCB:
[8] Packet Size, 0 == 9 flits, 1 == 11 flits
NCS:
[8] Packet Size, 0 == 1 or 2 flits, 1 == 3 flits
See Section 2.10, “Packet Matching Reference” for a listing of
opcodes that may be filtered per message class.
VNW 4:3 0x0 Virtual Network
b00 - VN0
b01 - VN1
b1x - VNA
--- 2:0 0x0 Reserved; Must write to 0 else behavior is undefined.
