Intel Xeon E5-2600 Series - PCU Box Level PMON State; PCU_MSR_PMON_BOX_CTL Register - Field Definitions

Reference Number: 327043-001 73
Intel® Xeon® Processor E5-2600 Product Family Uncore Performance Monitoring
2.6.3.1 PCU Box Level PMON State
The following registers represent the state governing all box-level PMUs in the PCU.
In the case of the PCU, the PCU_MSR_PMON_BOX_CTL register governs what happens when a freeze
signal is received (.frz_en). It also provides the ability to manually freeze the counters in the box
(.frz) and reset the generic state (.rst_ctrs and .rst_ctrl).
The PCU provides two extra MSRs that provide additional static performance information to software
but exist outside of the PMON infrastructure (e.g. they can’t be frozen or reset). They are included for
the convenience of software developers need to efficiently access this data.
PCU_MSR_PMON_CTR0 0x0C36 64 PCU PMON Counter 0
Box-Level Filter
PCU_MSR_PMON_BOX_FILTER 0x0C34 32 PCU PMON Filter
Generic Counter Control
PCU_MSR_PMON_CTL3 0x0C33 32 PCU PMON Control for Counter 3
PCU_MSR_PMON_CTL2 0x0C32 32 PCU PMON Control for Counter 2
PCU_MSR_PMON_CTL1 0x0C31 32 PCU PMON Control for Counter 1
PCU_MSR_PMON_CTL0 0x0C30 32 PCU PMON Control for Counter 0
Box-Level Control/Status
PCU_MSR_PMON_BOX_CTL 0x0C24 32 PCU PMON Box-Wide Control
Fixed (Non-PMON) Counters
PCU_MSR_CORE_C6_CTR 0x03FD 64 Fixed C-State Residency Counter
PCU_MSR_CORE_C3_CTR 0x03FC 64 Fixed C-State Residency Counter
Table 2-74. PCU_MSR_PMON_BOX_CTL Register – Field Definitions
Field Bits Attr
HW
Reset
Val
Description
rsv 31:18 RV 0 Reserved (?)
rsv 17 RV 0 Reserved; SW must write to 0 else behavior is undefined.
frz_en 16 WO 0 Freeze Enable.
If set to 1 and a freeze signal is received, the counters will be
stopped or ‘frozen’, else the freeze signal will be ignored.
rsv 15:9 RV 0 Reserved (?)
frz 8 WO 0 Freeze.
If set to 1 and the .frz_en is 1, the counters in this box will be
frozen.
rsv 7:2 RV 0 Reserved (?)
rst_ctrs 1 WO 0 Reset Counters.
When set to 1, the Counter Registers will be reset to 0.
rst_ctrl 0 WO 0 Reset Control.
When set to 1, the Counter Control Registers will be reset to 0.
Table 2-73. PCU Performance Monitoring MSRs (Sheet 2 of 2)
MSR Name
MSR
Address
Size
(bits)
Description
